Qiujing Calm Series Vortex Mixer Q5

Home / Products / Laboratory Instruments / Laboratory Mixer Series / Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5

Qiujing Calm Series Vortex Mixer Q5

Characteristic Advantage
Two safe operation modes "click" and "continuous", easy to switch, time function with positive timing and countdown to make the experiment more convenient and accurate;
In the shortest possible time to mix any liquid, powder needed to complete the work with high speed, high efficiency and high efficiency;
Perfect fuselage structure optimization design, so that it has enough counterweight weight and eccentric balance operation, providing a stable and quiet working platform for various oscillation mixing;
ST intelligent analysis and processing platform can respond to various mode work requirements, fully equipped with fast processing chipset and electronic sensing technology, easy to achieve intelligent control of speed, time and working mode;
Permanent magnet DC motor is not easy to heat, with over-temperature protection characteristics, to ensure that high-speed mixing can still work for a long time without trouble, simple integration, no spare parts, reduce running resistance, more powerful, reduce noise, avoid interference;

  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
  • Qiujing Calm Series Vortex Mixer Q5
Item Specification
Host parameters
Model No. Q5
Input Power Supply DC24V
Input Power 30W
Motor / Driving Mode DC24V Permanent Magnet Motor / Direct Drive
Control Mode PWM Speed Regulation
Operation Mode Light Sensor / Continuous Mode
Power Fuse Tube PPTC / Resettable Fuse, No Replacement Required
Maximum Load 1.0Kg
Speed Range 200‑3,000r/min ±5%
Shaking Mode Circular Motion
Orbit Diameter 4.5mm
Speed Function / Display Full Range / High‑brightness LED Digital Tube
Timer Function Digital Timing 1S‑999min / Countdown / Jog Forward Timing
Dimension: L × W × H 127mm×147mm×128mm
Weight 3.5Kg
Noise at High Rotation Speed ≤48dB(A)
Fastest Acceleration Time [sec] ≤3s
Fastest Deceleration Time [sec] ≤3s
Permissible Ambient Temperature / Relative Humidity +5~40℃ / 80%
Ingress Protection Rating IP20
Interference Suppression Standard EN 61010‑1, EN 61010‑2‑020, EN 61326‑1, EN 61010‑3‑2/A2

59661 59663-K16h 59662-71Ps
Angle type rotary head model Q5‑1 (Standard Configuration) Q5‑2 (Standard Configuration) Q5‑3 (Standard Configuration)
Applicable type Single‑tube universal 85mm diameter flask applicable 14 × 1.5ml/2ml centrifuge tubes
Maximum rotational speed 3000rpm 3000rpm 1500rpm
